X23Yu5 Fechtl table
Characteristics and properties of C23Y5
Characteristics and properties of X23Y5 Fehran (pdf)
| ALLOY | Material | Identification | DIN | UNS designation | ASTM | AMS |
|---|---|---|---|---|---|---|
| OCR23AL5 | 1.4725 | CrAl205 | 17 470 | K92 400 | B603IIB* | --- |
CHEMICAL COMPOSITION,(%)
| Chrome,(Cr) | Aluminum,(Al) | Iron,(Fe) | Carbon,(C) | Manganese,(Mn) | Silicon,(Si) | Copper,(Cu) | Nickel,(Ni) | Titanium,(Ti) | (Ti) Max0.6 | Rare Earth | The rest |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 21.0-23.5 | 4.6-5.8 | Basis | Max0.05 | Max0.7 | Max0.6 | --- | Max0.6 | --- | Zr, Max0.3 | --- | --- |
MECHANICAL PROPERTIES AT ROOM TEMPERATURE
| Number of bending cycles | Relative elongation, % |
|---|---|
| >5 | >12 |
PHYSICAL PROPERTIES AT ROOM TEMPERATURE
| Density, gr/cm³ | Hardness, HB | Tensile strength, MPa | Electrical resistance, Ohm*mm2/m | Maximum operating temperature, degree (°C) | Melting point, deg (°C) | Magnetic properties |
|---|---|---|---|---|---|---|
| 7.1 | 200-260 | 637-784 | 1.40 | 1300 | 1500 | Magneten |
LIFETIME
| Diameter 6.0m or more | Diameter 3.0-6.0mm | Diameter 1.5-3.0mm | Diameter 0.4-1.5mm |
|---|---|---|---|
| Diameter at T=1200ºC | At=1150°C | At=1100ºC | At=1000ºC |
| More than 3500 hours | More than 1800 hours | More than 1800hours | More than 900 hours |
OPERATION TIME
| DESCRIPTION OF THE MATERIAL: |
|---|
| -High corrosion resistance in air, oxidizing media, in vacuum; |
| GENERAL APPLICATIONS: Incinerators, high-temperature furnaces, resistor elements, heaters, industrial furnaces. |
